Working table, water temperature, oil temperature, current, and working timing are all in sight.
Famous brand hydraulic components are adopted, Cummins engine of which the operating life is long, and the power is driving and the operating speed is fast.
The moving arm can rotate 360°, can heaping while walking, front sugarcane grab can meet front and both side loading, working efficiency can be improved to great degree.
The big agricultural tires, walking quickly, can suitable for the hard field working environment.
Hydraulic walking, with the completion of the various operating actions scaffold, improve efficiency, each machine can save much labor force.
| TECHNICAL |
PARAMETERS |
| Total Weight |
9800kg |
| Grab and Load Weight |
500kg |
| Engine Brand |
Cummins |
| Rated Power |
215HP |
| Walking Speed |
<25KM/H |
| Swing Angle of Boom |
360 degree |
| Walking Pump Flux |
63/63ml/r |
| Working Pump Flux |
63ml/r |
| Max. Dumping Height |
7300mm |
| Max. Grabbing Radius |
5000mm |
| Overall Dimension(L*W*H) |
7500*3600*4000mm |
| Wheel Base |
3100mm |
| Distance Between Axles |
2500mm |
