| Excavator Part | Max.Digging Depth(mm) | 3000 |
| Max.Digging Height(mm) | 5600 | |
| Max.Digging Radius(mm) | 5200 | |
| Max.Dumping Height(mm) | 4300 | |
| Bucket Capacity(m3) | 0.4 | |
| Working Efficiency(m3/h) | 30-60 | |
| Working Times(times/min) | 4-7 | |
| Max.Swing Angle of Boom(°) | 180 | |
| Max.Hauling Force(KN) | 29 | |
| Loader Part | Max.Dumping Height(mm) | 2900 |
| Max.Dumping Distance(mm) | 950 | |
| Min.Rotary Radius(mm) | 5000 | |
| Rated Loading Mass(Kg) | 1500 | |
| Lifting Time of Movable Arm(s) | 3.5 | |
| Down Time of Movable Arm(s) | 2.5 | |
| Summational Time(s) | 7 | |
| Max. Breakout Force(KN) | 10.5 | |
| Engine | Cummins | 4BTA3.9-C100 |
| Rated Power(Kw) | 74 | |
| Rated Revolulution(r/min) | 2400 | |
| Specification | Working Pressure(mpa) | 28 |
| Max.Flux(ml/r) | 63 | |
| Total Weight(Kg) | 5500 | |
| Gradeability(%) | 25 | |
| Walking Speed(km/h) | <39 | |
| Distance Between Axles(mm) | 2700 | |
| Min Ground Clearance(mm) | 250 | |
| Overall Dimension(L*W*H)(mm) | 7600*2005*2700 |
