1. The joint venture with British ricardo technology production of diesel engine, low noise, large torque, energy conservation and environmental protection;
2. Using dry, multi-plate structure, combined with the main clutch, often with large torque backup, reliable work, etc;
3. Transmission of 4 f ﹢ 2 r mechanical shift gearbox, simple operation, convenient maintenance, reliable operation;
4. More than four, steering clutch for dry, steering clutch, hydraulic power manipulation, easy maintenance, light control;
5. Transmission: using two stage, straight teeth, big modulus gear transmission, has carrying capacity is strong, high reliability, etc;
6. Work unit: straight tilting shovel, Angle of sanitation shovels, shovel and scarifier device for users according to need to choose a variety of work.
| Model |
Unit |
T100G |
| Total weight |
kg |
10400 |
| Max towing force |
kN |
95 |
| Engine model |
|
LR6A3-23 |
| Engine rated power/speed |
kW/r/min |
81/2300 |
| Fuel consumption of the engine |
g/kw·h |
≤242 |
| Engine max torque |
N·m |
400 |
| Forward travel speed |
km/h |
Forward 4 gear: 2.6~10.3 |
| Backward travel speed |
km/h |
Backward 2 gear: 3.7~6.7 |
| Track board width |
mm |
450 |
| Land pressure |
kPa |
54.4 |
| Overall length |
mm |
4190 |
| Overall width |
mm |
2908 |
| Overall height |
mm |
2982 |
| Bulldozer width |
mm |
2908 |
| Bulldozer height |
mm |
960 |
| Blade max lifting height |
mm |
830 |
| Blade max digging depth |
mm |
370 |
| Traction equipment/Scarifier (optional) |
/ |
Fixed/Three teeth |
