1. The machine adopts technology production joint venture with British ricardo's turbo engine, low fuel consumption, the advantages of large torque reserve coefficient;
2. Steering clutch: using dry, multi-plate structure, manual hydraulic power manipulation, is easy to maintain, manipulation of light and other characteristics;
3. Configuration, type air filter is more adapt to the desert, desert and other special condition of coal demand;
4. Totally enclosed, low noise hexahedron cab, effectively reduce the ear noise, improve comfort, vision to work;
5. The adoption electronic monitoring electrical system, real-time monitoring of the whole machine, guarantee normal operation of the machine;
6. Work unit: straight tilting shovel, Angle of sanitation shovels, shovel, and other devices are available.
| Model |
Unit |
TS120 |
| Total weight |
kg |
13500 |
| Max towing force |
kN |
115 |
| Engine model |
|
LR6A3Z-20 |
| Engine rated power/speed |
kW/r/min |
93/2000 |
| Fuel consumption of the engine |
g/kw·h |
≤246 |
| Engine max torque |
N·m |
526 |
| Forward travel speed |
km/h |
Forward 4 gear: 2.4~10.6 |
| Backward travel speed |
km/h |
Backward 2 gear: 3.9~7.1 |
| Track board width |
mm |
720 |
| Land pressure |
kPa |
37 |
| Overall length |
mm |
4575 |
| Overall width |
mm |
3375 |
| Overall height |
mm |
2940 |
| Bulldozer width |
mm |
3375 |
| Bulldozer height |
mm |
1040 |
| Blade max lifting height |
mm |
955 |
| Blade max digging depth |
mm |
380 |
