1.0 Engine Details
(1) Model: Changcai 4L 68/Changchai 490/Changchai 485
(2) Engine type: In-line arrangement, water-cooled, four-cycle diesel Engine
(3) Rated Power: 37KW /29KW/26KW
(4) Rated Speed: 2200 r/min (rpm)
(5) Fuel Consumption ratio in standard working condition: 230g /kw.h
2.0 Transmission System
(1) Type: Fixed-spindle Power shift
(2) Shift gear control oil pressure: 1.2~1.5MPa
(3) Rated input speed: 2500 (rpm)
3.0 Bucket
(1) Bucket Capacity: 0.6 m3
(2) Bucket width: 1700mm
(3) Bucket type: Heavy-duty bolt on teeth
(4) Rated Load: 1000kg
(5) Operating Weight: 3000kg
4.0 Overall Dimensions
(1) Overall Length (Bucket on ground position): 4750mm
(2) Overall Height
(a) Ground to Cab Top: 2500mm
(b) Dumping Height: 2600mm
(c) Min. Base to the Ground: 230mm
(3) Overall Width: 1730mm
5.0 Operating Specifications
(1) Steering System: Articulated Frame with hydraulic power steering
(2) Min Turning Radius: 4000mm
(3) Driving System: Hydraulic converter
6.0 Brake System
(1) Service Brake: Four Wheel Hydraulic spread-shoed brake
(2) Parking Brake: Hand operated
7.0 Tyre
(1) Model:8.25-16
8.0 Wheelbase: 1580mm
9.0 Track: 1400mm
