1.0 Engine Details
(1) Model: Xinchai 498BT
(2) Engine type: In-line arrangement, water-cooled, four-cycle diesel Engine
(3) Rated Power: 37KW
(4) Rated Speed: 2200 r/min (rpm)
(5) Fuel Consumption ratio in standard working condition: 230g /kw.h
2.0 Transmission System
(1) Type: Fixed-spindle Power shift
(2) Shift gear control oil pressure: 1.2~1.5MPa
(3) Rated input speed: 2500 (rpm)
3.0 Bucket
(1) Bucket Capacity: 0.7 m3
(2) Bucket width: 1750mm
(3) Bucket type: Heavy-duty bolt on teeth
(4) Max. Breakout Force: 36.8KN
(5) Rated Load: 1500kg
(6) Operating Weight: 3500kg
4.0 Overall Dimensions
(1) Overall Length (Bucket on ground position): 5200mm
(2) Overall Height
(a) Ground to Cab Top: 2670mm
(b) Dumping Height: 2650mm
(c) Min. Base to the Ground: 260mm
(3) Overall Width: 1730mm
5.0 Operating Specifications
(1) Steering System: Articulated Frame with hydraulic power steering
(2) Min Turning Radius: 4500mm
(3) Driving System: Hydraulic converter
6.0 Brake System
(1) Service Brake: Four Wheel Hydraulic spread-shoed brake
(2) Parking Brake: Hand operated
7.0 Tyre
(1) Model:12-16.5
8.0 Wheelbase: 2100mm
9.0 Track: 1500mm
