| Specifications | |
| Rated operating capacity(kg) | 500 |
| Tipping load(kg) | 1000 |
| Bucket capacity(m3) | 0.25-0.4 |
| Operationg weight(kg) | 2200 |
| Max. travel speed(km/h) | 12 |
| Hydraulic pump flow(L/min) | 75 |
| Fuel tank capacity(L) | 50 |
| Tires | 27*8.5-15-8NHS |
| Overall dimensions(mm) | 2900×2000×1300 |
| Dimensions | |
| Height at maximum extension(mm) | 3300 |
| Height to bucket hinge pin(mm) | 2725 |
| Width with bucket(mm) | 1300 |
| Track width(mm) | 1080 |
| Wheelbase(mm) | 891 |
| Ground clearance(mm) | 150 |
| Dump angle | 40° |
| Dumping height(mm) | 2050 |
| Maximum reach(mm) | 790 |
| Rollback at ground | 26° |
| Angle of departure | 20° |
| Engine | |
| Maker/Model | YND485G |
| Net power | 40hp/2600rpm |
| Type | 4Cylinder in-line, Water cooled, 4 stroke, Diesel engine |
| Displacement(L) | 2.156 |
| Standard | |
| Standard bucket | |
| Open-type operator cab | |
| Hydraulic joystick controls | |
| Auxiliary hydraulic couplers | |
| Optional | |
| Enclosed operator cab | |
| Prehest starting assist system for extreme cold weather | |
| Cab fitted with a heater as standard | |
| Air conditioner |
