| Item |
Configuration |
| 1、 Feed proportioning system |
Aggregate bin (with filter net 12 m3 ) |
| Frequency control ring belt feeder |
| Belt 650mmx3.8m |
| Frequency variation electric roller 2.2kw |
| Collector belt conveyer |
| Belt 650mmx32m |
| Electrical roller 4kw |
| Vibrator MVE200/3 |
| 2、 Belt conveyer |
Belt 650mmx23m |
| Electrical roller 5.5kw |
| Belt conveyor frame and filter net |
| 3、 Burner |
Burner |
| Oil supply pump valve, pneumatic control valves and filter |
| Heavy, diesel oil pneumatic control switch, electric heater |
| Temperature auto control system |
| Diesel tank |
| 4、 Dry roller |
Roller φ2200×8200 |
| Machine frame, idler roll, stop roller, bearing, etc |
| Feed box, discharge box |
| Gear motor 11kw |
| 5、 Aggregate metering bin |
Aggregate metering hopper |
| Weighing sensor |
| Cylinder with valve |
| 6、 Powder metering bin |
Powder weighing hopper |
| Weighing sensor |
| Pneumatic butterfly valve |
| Powder screw |
| Vibrator |
| 7、 Asphalt metering spraying |
Asphalt metering box(conducting oil insulating) |
| Weighing sensor |
| Asphalt spray pump (Conducting oil insulating) |
| Metal hose |
| 8、 Mixing main engine |
Mixing main engine |
| Reducer |
| Motor 30kw |
| Weighing mixing frame, stairs platform ，railing |
| Cylinder with valve |
| 9、 Asphalt supply system |
Asphalt storage tank (Insulation, heating) |
| Double-layer insulation and heating asphalt piping, valves |
| Weighing three insulation valve (U.S. Technology) |
| Metal hose and thermometer, thermocouple |
| Cylinder with valve |
| Asphalt Weighing pump, feeding pump |
